P6KE15CA 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: STMicroelectronics P6KE15CA
- Breakdown Voltage: 14.3V
- Bidirectional Channels: 1
- Maximum Clamping Voltage: 27.2V
- Reverse Stand-Off Voltage (Vrwm): 12.8V
- Peak Pulse Current (Ipp)@10/1000us: 28A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Package: DO-15
- Manufacturer: STMicroelectronics
- Reverse Leakage Current (Ir): 1uA
- Unidirectional Channels: 0
