BC337-40 数据手册
数据手册规格
|
数据手册名称
|
BC337-40
|
|
文件大小
|
86.35
千字节
|
|
文件类型
|
pdf
|
|
页数
|
3
|
技术规格
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
LGE BC337-40
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
800mA
-
Power Dissipation (Pd):
625mW
-
Transition Frequency (fT):
210MHz
-
DC Current Gain (hFE@Ic,Vce):
250@100mA,1V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
45V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
700mV@500mA,50mA
-
Package:
TO-92-3
-
Manufacturer:
LGE
