技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: PAKER SMBJ28A
- Breakdown Voltage: 31.1V
- Maximum Clamping Voltage: 45.4V
- Reverse Leakage Current (Ir): 1uA
- Reverse Stand-Off Voltage (Vrwm): 28V
- Peak Pulse Current (Ipp)@10/1000us: 13.3A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Package: SMB(DO-214AA)
- Manufacturer: PAKER
- Bidirectional Channels: 1
- Unidirectional Channels: 1
- Peak Pulse Current (Ipp)@10/1000μs: 13.2A
