دیتاشیت LP3875ESX-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LP3875-ADJ |
|---|---|
| حجم فایل | 1701.556 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت LP3875-ADJ |
LP3875-ADJ Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP3875ESX-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 1.5A
- Output Voltage: 1.22V~6.4V
- Dropout Voltage: 0.55V@(1.5A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 7V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 5mA
- Package: TO-263-5
- Manufacturer: Texas Instruments
- Control Features: Enable
- Base Part Number: LP3875
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Current - Supply (Max): 15mA
- Part Status: Obsolete
- Current - Output: 1.5A
- PSRR: 73dB ~ 57dB (120Hz)
- Series: -
- Voltage - Output (Min/Fixed): 1.22V
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Current - Quiescent (Iq): 5mA
- Output Configuration: Positive
- Voltage Dropout (Max): 0.55V @ 1.5A
- Supplier Device Package: DDPAK/TO-263-5
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Input (Max): 7V
- Packaging: Cut Tape (CT)
- Voltage - Output (Max): 6.4V
- detail: Linear Voltage Regulator IC 1 Output 1.5A DDPAK/TO-263-5
