SMAJ170A دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SMAJ170A
|
|
حجم فایل
|
73.477
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Datasheet:
Yangzhou Yangjie Elec Tech SMAJ170A
-
Breakdown Voltage:
189V
-
Unidirectional Channels:
1
-
Maximum Clamping Voltage:
275V
-
Reverse Leakage Current (Ir):
5uA
-
Reverse Stand-Off Voltage (Vrwm):
170V
-
Peak Pulse Current (Ipp)@10/1000us:
1.45A
-
Peak Pulse Power Dissipation (Ppp)@10/1000us:
400W
-
Package:
SMA(DO-214AC)
-
Manufacturer:
Yangzhou Yangjie Elec Tech
-
Peak Pulse Current (Ipp)@10/1000μs:
1.4A
-
Peak Pulse Power Dissipation (Ppp)@10/1000μs:
400W
