SMBJ64A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: Littelfuse SMBJ64A
- Breakdown Voltage: 71.1V
- Unidirectional Channels: 1
- Maximum Clamping Voltage: 103V
- Reverse Stand-Off Voltage (Vrwm): 64V
- Peak Pulse Current (Ipp)@10/1000us: 5.9A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Package: SMB(DO-214AA)
- Manufacturer: Littelfuse
- Reverse Leakage Current (Ir): 5uA
- Peak Pulse Current (Ipp)@10/1000μs: 5.8A
