SMCJ60CA 数据手册
数据手册规格
|
数据手册名称
|
SMCJ60CA
|
|
文件大小
|
74.934
千字节
|
|
文件类型
|
pdf
|
|
页数
|
7
|
技术规格
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Datasheet:
MDD(Microdiode Electronics) SMCJ60CA
-
Package:
SMC(DO-214AB)
-
Manufacturer:
MDD(Microdiode Electronics)
-
Breakdown Voltage:
66.7V
-
Maximum Clamping Voltage:
96.8V
-
Reverse Stand-Off Voltage (Vrwm):
60V
-
Peak Pulse Current (Ipp)@10/1000us:
15.5A
-
Reverse Leakage Current (Ir):
5uA
-
Peak Pulse Current (Ipp)@10/1000μs:
15.5A
-
Peak Pulse Power Dissipation (Ppp)@10/1000μs:
1500W
-
Bidirectional Channels:
1
-
Peak Pulse Power Dissipation (Ppp)@10/1000us:
1500W
