- دیتاشیت 1.5KE30CA
1.5KE30CA دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | 1.5KE30CA |
|---|---|
| حجم فایل | 68.14 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت 1.5KE30CA |
دانلود دیتاشیت |
|---|
سایر مستندات
1.5KE 10 pages
1.5KE36A 4 pages
1.5KE36A 10 pages
1.5KE36A 6 pages
1.5KE36A 7 pages
Littelfuse 1.5KE39CA 6 pages
1.5KE91A 3 pages
1.5KE400CA 4 pages
1.5KE30CA 5 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: Littelfuse 1.5KE30CA
- Breakdown Voltage: 28.5V
- Bidirectional Channels: 1
- Maximum Clamping Voltage: 41.4V
- Reverse Stand-Off Voltage (Vrwm): 25.6V
- Peak Pulse Current (Ipp)@10/1000us: 36.7A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 1.5kW
- Package: DO-201
- Manufacturer: Littelfuse
- Reverse Leakage Current (Ir): 1uA
- Peak Pulse Current (Ipp)@10/1000μs: 36.23A
- Series: 1.5KE, TRANSIL™
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Voltage - Reverse Standoff (Typ): 25.6V
- Voltage - Breakdown (Min): 28.5V
- Voltage - Clamping (Max) @ Ipp: 53.5V
- Current - Peak Pulse (10/1000µs): 187A (8/20µs)
- Power - Peak Pulse: 1500W (1.5kW)
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 1450pF @ 1MHz
- Operating Temperature: -
- Mounting Type: Through Hole
- Package / Case: DO-201AA, DO-27, Axial
- Supplier Device Package: DO-201
- Base Part Number: 1.5KE
- detail: 53.5V Clamp 187A (8/20µs) Ipp Tvs Diode Through Hole DO-201
