دیتاشیت 1.5KE24CA
مشخصات دیتاشیت
| نام دیتاشیت |
1.5KE
|
| حجم فایل |
140.351
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Datasheet:
Littelfuse 1.5KE24CA
-
Breakdown Voltage:
22.8V
-
Bidirectional Channels:
1
-
Maximum Clamping Voltage:
33.2V
-
Reverse Stand-Off Voltage (Vrwm):
20.5V
-
Peak Pulse Current (Ipp)@10/1000us:
45.8A
-
Peak Pulse Power Dissipation (Ppp)@10/1000us:
1.5kW
-
Package:
DO-201
-
Manufacturer:
Littelfuse
-
Reverse Leakage Current (Ir):
5uA
-
Series:
1.5KE, TRANSIL™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Voltage - Reverse Standoff (Typ):
20.5V
-
Voltage - Breakdown (Min):
22.8V
-
Voltage - Clamping (Max) @ Ipp:
42.8V
-
Current - Peak Pulse (10/1000µs):
234A (8/20µs)
-
Power - Peak Pulse:
1500W (1.5kW)
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
1750pF @ 1MHz
-
Operating Temperature:
-
-
Mounting Type:
Through Hole
-
Package / Case:
DO-201AA, DO-27, Axial
-
Supplier Device Package:
DO-201
-
Base Part Number:
1.5KE
-
detail:
42.8V Clamp 234A (8/20µs) Ipp Tvs Diode Through Hole DO-201
