2SC2712 Datasheet

2SC2712

Datasheet specifications

Datasheet's name 2SC2712
File size 70.558 KB
File type pdf
Number of pages 2

Download Datasheet 2SC2712

Download Datasheet

Other documentations

2SC2712 3 pages

2SC2712 4 pages

2SC2712 4 pages

2SC2712 3 pages

2SC2712 2 pages

Technical specifications

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
  • Datasheet: UMW(Youtai Semiconductor Co., Ltd.) 2SC2712
  • Transistor Type: NPN
  • Operating Temperature: +150°C@(Tj)
  • Collector Current (Ic): 150mA
  • Power Dissipation (Pd): 150mW
  • Transition Frequency (fT): 80MHz
  • Collector Cut-Off Current (Icbo): 100nA
  • Collector-Emitter Breakdown Voltage (Vceo): 50V
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 100mV@100mA,10mA
  • Package: SOT-23-3
  • Manufacturer: UMW(Youtai Semiconductor Co., Ltd.)
  • DC Current Gain (hFE@Ic,Vce): 200@2mA,6V
