2SC2073 数据手册
其他文档
2SC2073 3 pages
技术规格
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: JSMSEMI 2SC2073
- Package: TO-220
- Manufacturer: JSMSEMI
- Transistor Type: NPN
- Operating Temperature: +150°C@(Tj)
- Collector Current (Ic): 1.5A
- Power Dissipation (Pd): 25W
- Transition Frequency (fT): 4MHz
- DC Current Gain (hFE@Ic,Vce): 40@500mA,10V
- Collector Cut-Off Current (Icbo): 10uA
- Collector-Emitter Breakdown Voltage (Vceo): 150V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 1.5V@500mA,50mA
