BAS16-7-F Datasheet
Datasheet specifications
| Datasheet's name | BAS16-7-F |
|---|---|
| File size | 96.416 KB |
| File type | |
| Number of pages | 4 |
Download Datasheet BAS16-7-F |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Diodes/Switching Diode
- Datasheet: Diodes Incorporated BAS16-7-F
- Power Dissipation: 350mW
- Diode Configuration: Single
- Reverse Voltage (Vr): 75V
- Operating Temperature: -65°C~+150°C@(Tj)
- Forward Voltage (Vf@If): 1.25V@150mA
- Reverse Leakage Current: 1uA@75V
- Reverse Recovery Time (trr): 4ns
- Average Rectified Current (Io): 200mA
- Package: SOT-23
- Manufacturer: Diodes Incorporated
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 85V
- Current - Average Rectified (Io): 200mA
- Voltage - Forward (Vf) (Max) @ If: 1.25V @ 150mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 1µA @ 75V
- Capacitance @ Vr, F: 2pF @ 0V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
- Operating Temperature - Junction: -55°C ~ 150°C
- Base Part Number: BAS16
- detail: Diode Standard 85V 200mA Surface Mount SOT-23-3 (TO-236)
