AO4803A Datasheet
Datasheet specifications
| Datasheet's name | AO4803A |
|---|---|
| File size | 62.548 KB |
| File type | |
| Number of pages | 6 |
Download Datasheet AO4803A |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Type: 2 P-Channel
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Datasheet: Alpha & Omega Semicon AO4803A
- Operating Temperature: -55°C~+150°C@(Tj)
- Power Dissipation (Pd): 2W
- Total Gate Charge (Qg@Vgs): 11nC@10V
- Drain Source Voltage (Vdss): 30V
- Input Capacitance (Ciss@Vds): 520pF@15V
- Continuous Drain Current (Id): 5A
- Gate Threshold Voltage (Vgs(th)@Id): 2.5V@250uA
- Drain Source On Resistance (RDS(on)@Vgs,Id): 46mΩ@10V,5A
- Package: SOP-8
- Manufacturer: Alpha & Omega Semicon
