BT136 Datasheet
Datasheet specifications
| Datasheet's name | BT136 |
|---|---|
| File size | 82.77 KB |
| File type | |
| Number of pages | 2 |
Download Datasheet BT136 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Triode/MOS Tube/Transistor/TRIACs
- SCR Type: Two-way thyristor
- Datasheet: Jiangsu Changjing Electronics Technology Co., Ltd. BT136
- Holding Current (Ih): 20mA
- Operating Temperature: -40°C~+125°C@(Tj)
- Gate Trigger Current(Igt): 10mA
- Gate Trigger Voltage (Vgt): 1.45V
- RMS On-State Current(It (rms)): 6A
- Peak Forward On?State Voltage (Vtm): 1.7V
- Average Gate Power Dissipation (PG(AV)): 500mW
- Peak Repetitive Off?State Voltage (Vdrm): 600V
- Peak non-repetitive surge current (Itsm@f): 25A@25ms
- Package: TO-220
- Manufacturer: Jiangsu Changjing Electronics Technology Co., Ltd.
