BSR16 SMD 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Transistor Type: PNP
- Current - Collector (Ic) (Max): 800mA
- Voltage - Collector Emitter Breakdown (Max): 60V
- Vce Saturation (Max) @ Ib, Ic: 1.6V @ 50mA, 500mA
- Current - Collector Cutoff (Max): 10nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 10V
- Power - Max: 350mW
- Frequency - Transition: 200MHz
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3
- Base Part Number: BSR16
- detail: Bipolar (BJT) Transistor PNP 60V 800mA 200MHz 350mW Surface Mount SOT-23-3
