دیتاشیت ISO35DWR-ND

مشخصات دیتاشیت

دانلود دیتاشیت ISO15(M), ISO35(M) Datasheet	ISO15(M), ISO35(M) Datasheet Datasheet

Channel Type: Unidirectional
Pulse Width Distortion (Max): -
Type: RS422, RS485
Number of Channels: 3
Isolated Power: No
Series: -
Packaging: Cut Tape (CT)
Voltage - Supply: 3.15V ~ 3.6V
Propagation Delay tpLH / tpHL (Max): -
Common Mode Transient Immunity (Min): 25kV/µs
Data Rate: 1Mbps
Technology: Capacitive Coupling
Supplier Device Package: 16-SOIC
Base Part Number: ISO35
Inputs - Side 1/Side 2: 2/1
Voltage - Isolation: 2500Vrms
Operating Temperature: -40°C ~ 85°C
Mounting Type: Surface Mount
Manufacturer: Texas Instruments
Part Status: Active
Rise / Fall Time (Typ): -
Package / Case: 16-SOIC (0.295", 7.50mm Width)
detail: RS422, RS485 Digital Isolator 2500Vrms 3 Channel 1Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
