IRFP23N50LPBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IRFP23N50LPBF
|
|
حجم فایل
|
89.888
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Vishay Intertech IRFP23N50LPBF
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
370W
-
Total Gate Charge (Qg@Vgs):
150nC@10V
-
Drain Source Voltage (Vdss):
500V
-
Input Capacitance (Ciss@Vds):
3600pF@25V
-
Continuous Drain Current (Id):
23A
-
Gate Threshold Voltage (Vgs(th)@Id):
5V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
235mΩ@14A,10V
-
Package:
TO-247
-
Manufacturer:
Vishay Intertech
