دیتاشیت LMR16020PDDAR

مشخصات دیتاشیت

دانلود دیتاشیت LMR16020 Datasheet	LMR16020 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Texas Instruments LMR16020PDDAR
Output Type: Adjustable
Input Voltage: 4.3V~60V
Output Voltage: 0.8V~50V
Number of Outputs: 1
Switching Frequency: 2.5MHz
Output Current (Max): 2A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: SOP-8-EP
Manufacturer: Texas Instruments
Frequency - Switching: 200kHz ~ 2.5MHz
Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
Supplier Device Package: 8-SO PowerPad
Voltage - Output (Min/Fixed): 0.8V
Current - Output: 2A
Output Configuration: Positive
Packaging: Cut Tape (CT)
Part Status: Active
Voltage - Output (Max): 50V
Series: SIMPLE SWITCHER®
Mounting Type: Surface Mount
Voltage - Input (Max): 60V
Base Part Number: LMR1602
Voltage - Input (Min): 4.3V
Synchronous Rectifier: No
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 2A 8-PowerSOIC (0.154", 3.90mm Width)
