MAX5026EUT+T Datasheet
Datasheet specifications
| Datasheet's name | MAX5026EUT+T |
|---|---|
| File size | 95.983 KB |
| File type | |
| Number of pages | 13 |
Download Datasheet MAX5026EUT+T |
Download Datasheet |
|---|
Other documentations
Part Numbering System 7 pages
MAX5025-28 13 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType
- Topology: Boost
- Datasheet: Analog Devices Inc./Maxim Integrated MAX5026EUT+T
- Output Type: Adjustable
- Input Voltage: 3V~11V
- Output Voltage: 3V~36V
- Number of Outputs: 1
- Switching Frequency: 500kHz
- Output Current (Max): 260mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: SOT-23-6
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Input (Max): 11V
- Voltage - Input (Min): 3V
- Output Configuration: Positive
- Supplier Device Package: SOT-23-6
- Package / Case: SOT-23-6
- Frequency - Switching: 500kHz
- Current - Output: 260mA (Switch)
- Part Status: Active
- Series: -
- Voltage - Output (Max): 36V
- Base Part Number: MAX5026
- Mounting Type: Surface Mount
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 3V
- Packaging: Cut Tape (CT)
- detail: Boost Switching Regulator IC Positive Adjustable 3V 1 Output 260mA (Switch) SOT-23-6
