- Datasheet MCP6S28-I/P
MCP6S28-I/P Datasheet
Datasheet specifications
| Datasheet's name | MCP6S28-I/P |
|---|---|
| File size | 87.468 KB |
| File type | |
| Number of pages | 42 |
Download Datasheet MCP6S28-I/P |
Download Datasheet |
|---|
Other documentations
Analog and Interface Product Guide 76 pages
MCP6S21/2/6/8 42 pages
Technical specifications
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Microchip Tech MCP6S28-I/P
- Number of Circuits: 8
- Gain Bandwidth Product(GBP): 12MHz
- Package: DIP-16
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Amplifier Type: Programmable Gain
- Output Type: Push-Pull, Rail-to-Rail
- Slew Rate: 22V/µs
- -3db Bandwidth: 12MHz
- Current - Input Bias: 1pA
- Voltage - Input Offset: 275µV
- Current - Supply: 1mA
- Current - Output / Channel: 30mA
- Voltage - Supply, Single/Dual (±): 2.5V ~ 5.5V
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-PDIP
- Base Part Number: MCP6S28
- detail: Programmable Gain Amplifier 8 Circuit Push-Pull, Rail-to-Rail 16-PDIP
