- دیتاشیت MCP6546T-I/OT
دیتاشیت MCP6546T-I/OT
مشخصات دیتاشیت
| نام دیتاشیت | MCP6546T-I/OT |
|---|---|
| حجم فایل | 101.779 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 44 |
MCP6546T-I/OT |
دانلود دیتاشیت |
|---|
سایر مستندات
Analog and Interface Product Guide 76 pages
MCP6546-49 44 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Microchip Tech MCP6546T-I/OT
- Output Type: CMOS;Open Drain;轨到轨;TTL
- Supply Current: 1uA
- Supply Voltage: 1.6V~5.5V
- Number of Elements: 1
- Operating Temperature: -40°C~+85°C
- Propagation Delay Time: 8us
- Input Bias Current (Ib): 1pA
- Input Offset Voltage (Vos): 7mV
- Input Hysteresis Voltage (Vhys): 6.5mV
- Common Mode Rejection Ratio (CMRR): 70dB
- Package: SOT-23-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: General Purpose
- Voltage - Supply, Single/Dual (±): 1.6V ~ 5.5V
- Voltage - Input Offset (Max): 7mV @ 5.5V
- Current - Input Bias (Max): 1pA @ 5.5V
- Current - Output (Typ): 30mA
- Current - Quiescent (Max): 1µA
- CMRR, PSRR (Typ): 70dB CMRR, 80dB PSRR
- Propagation Delay (Max): 8µs
- Hysteresis: 6.5mV
- Package / Case: SC-74A, SOT-753
- Mounting Type: Surface Mount
- Supplier Device Package: SOT-23-5
- Base Part Number: MCP6546
- detail: Comparator General Purpose CMOS, Open-Drain, Rail-to-Rail, TTL SOT-23-5
