MAX14756EUE+T
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Maxim Integrated |
| Package | 16-TSSOP (0.173", 4.40mm Width) |
| Datasheet | MAX14756-58 |
| Description | 4 Circuit IC Switch 1:1 10Ohm 16-TSSOP |
فروشنده های MAX14756EUE+T
فروشگاهی یافت نشد
مشخصات MAX14756EUE+T
- Multiplexer/Demultiplexer Circuit 1:1
- Part Status Active
- Charge Injection 580pC
- -3db Bandwidth 145MHz
- Operating Temperature -40°C ~ 85°C (TA)
- Voltage - Supply, Dual (V±) ±10V ~ 35V
- Supplier Device Package 16-TSSOP
- Package / Case 16-TSSOP (0.173", 4.40mm Width)
- Switch Time (Ton, Toff) (Max) 60µs, 3µs
- Packaging Tube
- Channel-to-Channel Matching (ΔRon) 300mOhm
- Voltage - Supply, Single (V+) 10V ~ 70V
- Channel Capacitance (CS(off), CD(off)) 35pF
- Switch Circuit SPST - NC
- Mounting Type Surface Mount
- Series -
- Crosstalk -96dB @ 10MHz
- Number of Circuits 4
- Manufacturer Maxim Integrated
- Current - Leakage (IS(off)) (Max) 2.5nA
- Base Part Number MAX14756
- On-State Resistance (Max) 10Ohm
- detail 4 Circuit IC Switch 1:1 10Ohm 16-TSSOP
