HCNW2211-000E
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Broadcom/AVAGO |
| Package | 8-DIP (0.400", 10.16mm) |
| Datasheet | HCNW2211-000E |
| Description | Logic Output Optoisolator 5MBd Push-Pull, Totem Pole 5000Vrms 1 Channel 10kV/µs CMTI 8-DIP |
فروشنده های HCNW2211-000E
فروشگاهی یافت نشد
مشخصات HCNW2211-000E
- RoHS true
- Category Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
- Data Rate 5Mbit/s
- Datasheet Broadcom/AVAGO HCNW2211-000E
- Input Type DC
- Supply Voltage 4.5V~20V
- Number of Channels 1
- Operating Temperature -40°C~+85°C
- Isolation Voltage(rms) 5000V
- Propagation Delay tpLH/tpHL 180ns;160ns
- Common Mode Transient Immunity (CMTI) 10kV/us
- Package DIP-8
- Manufacturer Broadcom/AVAGO
- Series -
- Packaging Tube
- Part Status Active
- Inputs - Side 1/Side 2 1/0
- Voltage - Isolation 5000Vrms
- Common Mode Transient Immunity (Min) 10kV/µs
- Output Type Push-Pull, Totem Pole
- Current - Output / Channel 25mA
- Propagation Delay tpLH / tpHL (Max) 180ns, 160ns (Typ)
- Rise / Fall Time (Typ) 30ns, 7ns
- Voltage - Forward (Vf) (Typ) 1.5V
- Current - DC Forward (If) (Max) 10mA
- Voltage - Supply 4.5V ~ 20V
- Mounting Type Through Hole
- Package / Case 8-DIP (0.400", 10.16mm)
- Supplier Device Package 8-DIP
- detail Logic Output Optoisolator 5MBd Push-Pull, Totem Pole 5000Vrms 1 Channel 10kV/µs CMTI 8-DIP
