ACPL-M61L-560E
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Broadcom/AVAGO |
| Package | 6-SOIC (0.173", 4.40mm Width), 5 Leads |
| Datasheet | ACPL-M61L-560E |
| Description | Logic Output Optoisolator 10MBd Push-Pull, Totem Pole 3750Vrms 1 Channel 20kV/µs CMTI 5-SO |
فروشنده های ACPL-M61L-560E
فروشگاهی یافت نشد
مشخصات ACPL-M61L-560E
- RoHS true
- Category Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
- Data Rate 10Mbit/s
- Datasheet Broadcom/AVAGO ACPL-M61L-560E
- Input Type DC
- Supply Voltage 2.7V~5.5V
- Number of Channels 1
- Operating Temperature -40°C~+105°C
- Isolation Voltage(rms) 3750V
- Propagation Delay tpLH/tpHL 80ns
- Common Mode Transient Immunity (CMTI) 20kV/us
- Package SO-5
- Manufacturer Broadcom/AVAGO
- Series -
- Packaging Cut Tape (CT)
- Part Status Discontinued at Digi-Key
- Inputs - Side 1/Side 2 1/0
- Voltage - Isolation 3750Vrms
- Common Mode Transient Immunity (Min) 20kV/µs
- Output Type Push-Pull, Totem Pole
- Current - Output / Channel 10mA
- Propagation Delay tpLH / tpHL (Max) 80ns, 80ns
- Rise / Fall Time (Typ) 12ns, 12ns
- Voltage - Forward (Vf) (Typ) 1.3V
- Current - DC Forward (If) (Max) 8mA
- Voltage - Supply 2.7V ~ 5.5V
- Mounting Type Surface Mount
- Package / Case 6-SOIC (0.173", 4.40mm Width), 5 Leads
- Supplier Device Package 5-SO
- detail Logic Output Optoisolator 10MBd Push-Pull, Totem Pole 3750Vrms 1 Channel 20kV/µs CMTI 5-SO
