FSA2467MPX

FSA2467MPX

FSA2467MPX

در 0 فروشگاه

قیمت هنوز مشخص نشده است

این محصول در حال حاضر فروشنده ای ندارد!

مشخصات فنی:
Manufacturer onsemi
Package 16-WFQFN Exposed Pad
Datasheet FSA2467
Description 2 Circuit IC Switch 2:2 400Ohm (Typ) 16-MLP (3x3)

sellers FSA2467MPX

فروشگاهی یافت نشد

پالت

تغییرات قیمت

پالت

مشخصات

  • RoHS true
  • Category Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
  • Datasheet onsemi FSA2467MPX
  • Turn-on time 50ns
  • Supply Voltage 1.65V~4.3V
  • Switch Circuit DPDT(DPDT)
  • Number of Channels 2
  • On-State Resistance (Max) 400Ω
  • Package MLP-16
  • Manufacturer onsemi
  • Series -
  • Packaging Cut Tape (CT)
  • Part Status Active
  • Multiplexer/Demultiplexer Circuit 2:2
  • Number of Circuits 2
  • Channel-to-Channel Matching (ΔRon) 40mOhm (Min)
  • Voltage - Supply, Single (V+) 1.65V ~ 4.3V
  • Voltage - Supply, Dual (V±) -
  • Switch Time (Ton, Toff) (Max) 50ns, 32ns
  • -3db Bandwidth 85MHz
  • Charge Injection 15pC
  • Channel Capacitance (CS(off), CD(off)) 32pF
  • Current - Leakage (IS(off)) (Max) 10nA
  • Crosstalk -75dB @ 100kHz
  • Operating Temperature -40°C ~ 85°C (TA)
  • Mounting Type Surface Mount
  • Package / Case 16-WFQFN Exposed Pad
  • Supplier Device Package 16-MLP (3x3)
  • Base Part Number FSA24
  • detail 2 Circuit IC Switch 2:2 400Ohm (Typ) 16-MLP (3x3)
