2N6288G
در 1 فروشگاه
قیمت هنوز مشخص نشده است
| Manufacturer | onsemi |
| Package | TO-220-3 |
| Datasheet | 2N61xx, 2N62xx |
| Description | Bipolar (BJT) Transistor NPN 30V 7A 4MHz 40W Through Hole TO-220AB |
sellers 2N6288G
تغییرات قیمت
مشخصات
- RoHS true
- Category Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet onsemi 2N6288G
- Transistor Type NPN
- Operating Temperature -65°C~+150°C@(Tj)
- Collector Current (Ic) 7A
- Power Dissipation (Pd) 40W
- Transition Frequency (fT) 10MHz
- DC Current Gain (hFE@Ic,Vce) 30@3A,4V
- Collector Cut-Off Current (Icbo) 1mA
- Collector-Emitter Breakdown Voltage (Vceo) 30V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib) 3.5V@7A,3A
- Package TO-220
- Manufacturer onsemi
- Series -
- Packaging Tube
- Part Status Obsolete
- Current - Collector (Ic) (Max) 7A
- Voltage - Collector Emitter Breakdown (Max) 30V
- Vce Saturation (Max) @ Ib, Ic 3.5V @ 3A, 7A
- Current - Collector Cutoff (Max) 1mA
- DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 3A, 4V
- Power - Max 40W
- Frequency - Transition 4MHz
- Mounting Type Through Hole
- Package / Case TO-220-3
- Supplier Device Package TO-220AB
- Base Part Number 2N6288
- detail Bipolar (BJT) Transistor NPN 30V 7A 4MHz 40W Through Hole TO-220AB
