FODM8071R2
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | onsemi |
| Package | 6-SOIC (0.173", 4.40mm Width), 5 Leads |
| Datasheet | FODM8071 |
| Description | Logic Output Optoisolator 20Mbps Push-Pull, Totem Pole 3750Vrms 1 Channel 20kV/µs CMTI 5-Mini-Flat |
فروشنده های FODM8071R2
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات FODM8071R2
- RoHS true
- Category Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
- Data Rate 20Mbit/s
- Datasheet onsemi FODM8071R2
- Input Type DC
- Supply Voltage 3V~5.5V
- Number of Channels 1
- Operating Temperature -40°C~+110°C
- Isolation Voltage(rms) 3750V
- Propagation Delay tpLH/tpHL 55ns
- Common Mode Transient Immunity (CMTI) 20kV/us
- Package SOIC-5
- Manufacturer onsemi
- Series -
- Packaging Cut Tape (CT)
- Part Status Active
- Inputs - Side 1/Side 2 1/0
- Voltage - Isolation 3750Vrms
- Common Mode Transient Immunity (Min) 20kV/µs
- Output Type Push-Pull, Totem Pole
- Current - Output / Channel 10mA
- Propagation Delay tpLH / tpHL (Max) 55ns, 55ns
- Rise / Fall Time (Typ) 5.8ns, 5.3ns
- Voltage - Forward (Vf) (Typ) 1.35V
- Current - DC Forward (If) (Max) 20mA
- Voltage - Supply 3V ~ 5.5V
- Mounting Type Surface Mount
- Package / Case 6-SOIC (0.173", 4.40mm Width), 5 Leads
- Supplier Device Package 5-Mini-Flat
- Base Part Number FODM80
- detail Logic Output Optoisolator 20Mbps Push-Pull, Totem Pole 3750Vrms 1 Channel 20kV/µs CMTI 5-Mini-Flat
