FDMC7672S-F126
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | ON Semiconductor |
| Package | 8-PowerWDFN |
| Datasheet | FDMC7672S |
| Description | N-Channel 30V 14.8A (Ta) 2.3W (Ta), 36W (Tc) Surface Mount 8-MLP (3.3x3.3) |
فروشنده های FDMC7672S-F126
فروشگاهی یافت نشد
مشخصات FDMC7672S-F126
- Manufacturer ON Semiconductor
- Series PowerTrench®, SyncFET™
- Packaging Cut Tape (CT)
- Part Status Obsolete
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 30V
- Current - Continuous Drain (Id) @ 25°C 14.8A (Ta)
- Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
- Rds On (Max) @ Id, Vgs 6mOhm @ 14.8A, 10V
- Vgs(th) (Max) @ Id 3V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs 42nC @ 10V
- Vgs (Max) ±20V
- Input Capacitance (Ciss) (Max) @ Vds 2520pF @ 15V
- FET Feature -
- Power Dissipation (Max) 2.3W (Ta), 36W (Tc)
- Operating Temperature -55°C ~ 150°C (TJ)
- Mounting Type Surface Mount
- Supplier Device Package 8-MLP (3.3x3.3)
- Package / Case 8-PowerWDFN
- Base Part Number FDMC76
- detail N-Channel 30V 14.8A (Ta) 2.3W (Ta), 36W (Tc) Surface Mount 8-MLP (3.3x3.3)
