مشخصات FDN337N-F169
- Manufacturer ON Semiconductor
- Series -
- Packaging Tape & Reel (TR)
- Part Status Obsolete
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 30V
- Current - Continuous Drain (Id) @ 25°C 2.2A (Ta)
- Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
- Rds On (Max) @ Id, Vgs 65mOhm @ 2.2A, 4.5V
- Vgs(th) (Max) @ Id 1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs 9nC @ 4.5V
- Vgs (Max) ±8V
- Input Capacitance (Ciss) (Max) @ Vds 300pF @ 10V
- FET Feature -
- Power Dissipation (Max) 500mW (Ta)
- Operating Temperature -55°C ~ 150°C (TJ)
- Mounting Type Surface Mount
- Supplier Device Package SOT-23-3
- Package / Case TO-236-3, SC-59, SOT-23-3
- Base Part Number FDN337
- detail N-Channel 30V 2.2A (Ta) 500mW (Ta) Surface Mount SOT-23-3
