SMAJ33A-TR
在 0 商店
价格尚未确定
该产品目前没有卖家！
| Manufacturer | STMicroelectronics |
| Package | DO-214AC, SMA |
| Datasheet | SMAJ Datasheet |
| Description | 69.7V Clamp 33A (8/20µs) Ipp Tvs Diode Surface Mount SMA (DO-214AC) |
sellers SMAJ33A-TR
未找到商店
规格
- RoHS true
- Category TVS/Fuse/Board Level Protection/TVS
- Datasheet STMicroelectronics SMAJ33A-TR
- Breakdown Voltage 36.7V
- Unidirectional Channels 1
- Maximum Clamping Voltage 69.7V
- Reverse Leakage Current (Ir) 0.2uA
- Reverse Stand-Off Voltage (Vrwm) 33V
- Peak Pulse Current (Ipp)@10/1000us 33A@8/20us
- Peak Pulse Power Dissipation (Ppp)@10/1000us 400W
- Package SMA(DO-214AC)
- Manufacturer STMicroelectronics
- Series SMAJ, TRANSIL™
- Packaging Cut Tape (CT)
- Part Status Active
- Type Zener
- Voltage - Reverse Standoff (Typ) 33V
- Voltage - Breakdown (Min) 36.7V
- Voltage - Clamping (Max) @ Ipp 69.7V
- Current - Peak Pulse (10/1000µs) 33A (8/20µs)
- Power - Peak Pulse 400W
- Power Line Protection No
- Applications General Purpose
- Capacitance @ Frequency -
- Operating Temperature -55°C ~ 150°C (TJ)
- Mounting Type Surface Mount
- Package / Case DO-214AC, SMA
- Supplier Device Package SMA (DO-214AC)
- Base Part Number SMAJ
- detail 69.7V Clamp 33A (8/20µs) Ipp Tvs Diode Surface Mount SMA (DO-214AC)
卖家
未找到商店
