TPS70933QDBVRQ1
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Texas Instruments |
| Package | SC-74A, SOT-753 |
| Datasheet | TPS709-Q1 |
| Description | Linear Voltage Regulator IC 1 Output 150mA SOT-23-5 |
فروشنده های TPS70933QDBVRQ1
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات TPS70933QDBVRQ1
- RoHS true
- Category Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet Texas Instruments TPS70933QDBVRQ1
- Output Type Fixed
- Output Current 150mA
- Output Voltage 3.3V
- Dropout Voltage 1.54V@(150mA)
- Output Polarity Positive
- Number of Outputs 1
- Maximum Input Voltage 30V
- Operating Temperature -40°C~+125°C
- Quiescent Current (Ground Current) 2.05uA
- Power Supply Rejection Ratio (PSRR) 80dB@(10Hz),52dB@(1kHz)
- Package SOT-23-5
- Manufacturer Texas Instruments
- Current - Quiescent (Iq) 2.05µA
- Voltage - Input (Max) 30V
- Packaging Cut Tape (CT)
- PSRR 80dB ~ 52dB (10Hz ~ 1kHz)
- Package / Case SC-74A, SOT-753
- Voltage Dropout (Max) 1.54V @ 150mA
- Current - Output 150mA
- Current - Supply (Max) 350µA
- Number of Regulators 1
- Supplier Device Package SOT-23-5
- Voltage - Output (Max) -
- Mounting Type Surface Mount
- Protection Features Over Current, Over Temperature, Reverse Current, Under Voltage Lockout (UVLO)
- Base Part Number TPS709
- Voltage - Output (Min/Fixed) 3.3V
- Control Features Enable
- Part Status Active
- Series Automotive, AEC-Q100
- Output Configuration Positive
- detail Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
