CSD18533Q5A
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Texas Instruments |
| Package | 8-PowerTDFN |
| Datasheet | CSD18533Q5A |
| Description | N-Channel 60V 17A (Ta), 100A (Tc) 3.2W (Ta), 116W (Tc) Surface Mount 8-VSONP (5x6) |
فروشنده های CSD18533Q5A
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات CSD18533Q5A
- RoHS true
- Type N Channel
- Category Triode/MOS Tube/Transistor/MOSFETs
- Datasheet Texas Instruments CSD18533Q5A
- Operating Temperature -55°C~+150°C@(Tj)
- Power Dissipation (Pd) 3.2W;116W
- Total Gate Charge (Qg@Vgs) 36nC@10V
- Drain Source Voltage (Vdss) 60V
- Input Capacitance (Ciss@Vds) 2750pF@30V
- Continuous Drain Current (Id) 17A;100A
- Gate Threshold Voltage (Vgs(th)@Id) 2.3V@250uA
- Drain Source On Resistance (RDS(on)@Vgs,Id) 5.9mΩ@10V,18A
- Package VSONP-8
- Manufacturer Texas Instruments
- Power Dissipation (Max) 3.2W (Ta), 116W (Tc)
- Input Capacitance (Ciss) (Max) @ Vds 2750pF @ 30V
- Vgs (Max) ±20V
- Supplier Device Package 8-VSONP (5x6)
- Packaging Cut Tape (CT)
- Mounting Type Surface Mount
- Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
- Base Part Number CSD1853
- Vgs(th) (Max) @ Id 2.3V @ 250µA
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- FET Feature -
- Package / Case 8-PowerTDFN
- Part Status Active
- Series NexFET™
- Gate Charge (Qg) (Max) @ Vgs 36nC @ 10V
- Rds On (Max) @ Id, Vgs 5.9mOhm @ 18A, 10V
- Current - Continuous Drain (Id) @ 25°C 17A (Ta), 100A (Tc)
- Drain to Source Voltage (Vdss) 60V
- detail N-Channel 60V 17A (Ta), 100A (Tc) 3.2W (Ta), 116W (Tc) Surface Mount 8-VSONP (5x6)
