LM1117T-3.3/NOPB
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Texas Instruments |
| Package | TO-220-3 |
| Datasheet | LM1117 |
| Description | Linear Voltage Regulator IC 1 Output 800mA TO-220-3 |
فروشنده های LM1117T-3.3/NOPB
فروشگاهی یافت نشد
مشخصات LM1117T-3.3/NOPB
- RoHS true
- Category Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet Texas Instruments LM1117T-3.3/NOPB
- Output Type Fixed
- Output Current 800mA
- Output Voltage 3.3V
- Dropout Voltage 1.2V@(800mA)
- Output Polarity Positive
- Number of Outputs 1
- Maximum Input Voltage 15V
- Operating Temperature 0°C~+125°C
- Quiescent Current (Ground Current) 5mA
- Power Supply Rejection Ratio (PSRR) 75dB@(120Hz)
- Package TO-220
- Manufacturer Texas Instruments
- Control Features -
- Base Part Number LM1117
- Package / Case TO-220-3
- Current - Supply (Max) 10mA
- Part Status Obsolete
- Current - Output 800mA
- PSRR 75dB (120Hz)
- Series LM1117-3.3
- Voltage - Output (Min/Fixed) 3.3V
- Mounting Type Through Hole
- Number of Regulators 1
- Current - Quiescent (Iq) 5mA
- Output Configuration Positive
- Voltage Dropout (Max) 1.2V @ 800mA
- Supplier Device Package TO-220-3
- Protection Features Over Current, Over Temperature
- Voltage - Input (Max) 15V
- Packaging Tube
- Voltage - Output (Max) -
- detail Linear Voltage Regulator IC 1 Output 800mA TO-220-3
