STM32L475VCT6
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | STMicroelectronics |
| Package | 100-LQFP |
| Datasheet | STM32L475xx Datasheet |
| Description | ARM® Cortex®-M4 STM32L4 Microcontroller IC 32-Bit 80MHz 256KB (256K x 8) FLASH 100-LQFP (14x14) |
فروشنده های STM32L475VCT6
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات STM32L475VCT6
- RoHS true
- EEPROM -
- CPU Core ARM Cortex-M4
- Category Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size 128KB
- Watchdog Yes
- ADC (Bit) 12bit
- DAC (Bit) 12bit
- Datasheet STMicroelectronics STM32L475VCT6
- PWM (Bit) -
- Real-Time Clock -
- CPU Maximum Speed 80MHz
- GPIO Ports Number 82
- Low-Voltage Detect -
- CCP Capture/Compare -
- Internal Comparator -
- Internal Oscillator Yes
- Peripheral/Function PWM;WDT
- Program Memory Type FLASH
- Direct Memory Access Yes
- Program Storage Size 256KB
- Universal Serial Bus Yes
- communication protocol -
- Operating Voltage Range 1.71V~3.6V
- Infrared Data Association Yes
- Operating Temperature Range -40°C~+85°C
- Secure Digital Input and Output -
- Package LQFP-100(14x14)
- Manufacturer STMicroelectronics
- Series STM32L4
- Packaging Tray
- Part Status Active
- Core Processor ARM® Cortex®-M4
- Core Size 32-Bit
- Speed 80MHz
- Connectivity CANbus, EBI/EMI, I²C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB OTG
- Peripherals Brown-out Detect/Reset, DMA, PWM, WDT
- Number of I/O 82
- Program Memory Size 256KB (256K x 8)
- EEPROM Size -
- Voltage - Supply (Vcc/Vdd) 1.71V ~ 3.6V
- Data Converters A/D 16x12b; D/A 2x12b
- Oscillator Type Internal
- Operating Temperature -40°C ~ 85°C (TA)
- Mounting Type Surface Mount
- Package / Case 100-LQFP
- Supplier Device Package 100-LQFP (14x14)
- Base Part Number STM32L475
- detail ARM® Cortex®-M4 STM32L4 Microcontroller IC 32-Bit 80MHz 256KB (256K x 8) FLASH 100-LQFP (14x14)
