ESDAVLC6-2BLY
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | STMicroelectronics |
| Package | TO-236-3, SC-59, SOT-23-3 |
| Datasheet | ESDAVLC6-2BLY Datasheet |
| Description | 17V Clamp 5.5A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 |
فروشنده های ESDAVLC6-2BLY
فروشگاهی یافت نشد
مشخصات ESDAVLC6-2BLY
- RoHS true
- Category TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet STMicroelectronics ESDAVLC6-2BLY
- Clamping Voltage@Ipp 17V
- Operating Temperature -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR) 6V
- Peak Pulse Power(Ppp)@8/20us 140W
- Junction Capacitance(Cj)@1MHz 0.95pF@1MHz
- Peak Pulse Current(Ipp)@8/20us 5.5A@(8/20us)
- Reverse Stand-Off Voltage (Vrwm) 5V
- Package SOT-23-3
- Manufacturer STMicroelectronics
- Series Automotive, AEC-Q101, ESDA
- Packaging Cut Tape (CT)
- Part Status Active
- Type Zener
- Bidirectional Channels 2
- Voltage - Reverse Standoff (Typ) 5V
- Voltage - Breakdown (Min) 6V
- Voltage - Clamping (Max) @ Ipp 17V
- Current - Peak Pulse (10/1000µs) 5.5A (8/20µs)
- Power - Peak Pulse 140W
- Power Line Protection No
- Applications Automotive
- Capacitance @ Frequency 0.95pF @ 1MHz
- Mounting Type Surface Mount
- Package / Case TO-236-3, SC-59, SOT-23-3
- Supplier Device Package SOT-23-3
- Base Part Number ESDAVLC6
- detail 17V Clamp 5.5A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3
