ISO7760DBQR
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Texas Instruments |
| Package | 16-SSOP (0.154", 3.90mm Width) |
| Datasheet | ISO7760-63 Datasheet |
| Description | General Purpose Digital Isolator 3000Vrms 6 Channel 100Mbps 85kV/µs CMTI 16-SSOP (0.154", 3.90mm Width) |
فروشنده های ISO7760DBQR
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات ISO7760DBQR
- RoHS true
- Category Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate 100Mbps
- Datasheet Texas Instruments ISO7760DBQR
- Applications General-purpose
- Supply Voltage 2.25V~5.5V
- Forward Channel 6
- Reverse channel 0
- Number of Channels 6
- Isolation Technology 电容隔离
- Operating Temperature -55°C~+125°C
- Voltage Isolation or Not Without voltage isolation
- Package SSOP-16-150mil-0.635mm
- Manufacturer Texas Instruments
- Channel Type Unidirectional
- Pulse Width Distortion (Max) 4.9ns
- Type General Purpose
- Isolated Power No
- Series -
- Packaging Cut Tape (CT)
- Voltage - Supply 2.25V ~ 5.5V
- Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
- Common Mode Transient Immunity (Min) 85kV/µs
- Technology Capacitive Coupling
- Supplier Device Package 16-SSOP
- Base Part Number ISO776
- Inputs - Side 1/Side 2 6/0
- Voltage - Isolation 3000Vrms
- Mounting Type Surface Mount
- Part Status Active
- Rise / Fall Time (Typ) 1.1ns, 1.4ns
- Package / Case 16-SSOP (0.154", 3.90mm Width)
- detail General Purpose Digital Isolator 3000Vrms 6 Channel 100Mbps 85kV/µs CMTI 16-SSOP (0.154", 3.90mm Width)
