STF13NM60N-H
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | STMicroelectronics |
| Package | TO-220-3 Full Pack |
| Datasheet | STF13NM60N-H |
| Description | N-Channel 600V 11A (Tc) 25W (Tc) Through Hole TO-220FP |
فروشنده های STF13NM60N-H
فروشگاهی یافت نشد
مشخصات STF13NM60N-H
- Manufacturer STMicroelectronics
- Series MDmesh™ II
- Packaging Tube
- Part Status Obsolete
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 600V
- Current - Continuous Drain (Id) @ 25°C 11A (Tc)
- Drive Voltage (Max Rds On, Min Rds On) 10V
- Rds On (Max) @ Id, Vgs 360mOhm @ 5.5A, 10V
- Vgs(th) (Max) @ Id 4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs 30nC @ 10V
- Vgs (Max) ±25V
- Input Capacitance (Ciss) (Max) @ Vds 790pF @ 50V
- FET Feature -
- Power Dissipation (Max) 25W (Tc)
- Operating Temperature 150°C (TJ)
- Mounting Type Through Hole
- Supplier Device Package TO-220FP
- Package / Case TO-220-3 Full Pack
- Base Part Number STF13
- detail N-Channel 600V 11A (Tc) 25W (Tc) Through Hole TO-220FP
