ADG1414BRUZ-REEL7
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Analog Devices |
| Package | 24-TSSOP (0.173", 4.40mm Width) |
| Datasheet | ADG1414 |
| Description | 8 Circuit IC Switch 1:1 11.5Ohm 24-TSSOP |
فروشنده های ADG1414BRUZ-REEL7
فروشگاهی یافت نشد
مشخصات ADG1414BRUZ-REEL7
- RoHS true
- Category Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet Analog Devices ADG1414BRUZ-REEL7
- Turn-on time 93ns
- Supply Voltage 12V
- Switch Circuit SPST(SPST)-Normal Open
- Number of Channels 8
- On-State Resistance (Max) 11.5Ω
- Package TSSOP-24
- Manufacturer Analog Devices
- Series -
- Packaging Cut Tape (CT)
- Part Status Active
- Multiplexer/Demultiplexer Circuit 1:1
- Number of Circuits 8
- Channel-to-Channel Matching (ΔRon) 550mOhm
- Voltage - Supply, Single (V+) 12V
- Voltage - Supply, Dual (V±) ±4.5V ~ 16.5V
- Switch Time (Ton, Toff) (Max) 93ns, 35ns
- -3db Bandwidth 256MHz
- Charge Injection 10pC
- Channel Capacitance (CS(off), CD(off)) 8pF
- Current - Leakage (IS(off)) (Max) 150pA
- Crosstalk -75dB @ 1MHz
- Operating Temperature -40°C ~ 125°C (TA)
- Mounting Type Surface Mount
- Package / Case 24-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package 24-TSSOP
- Base Part Number ADG1414
- detail 8 Circuit IC Switch 1:1 11.5Ohm 24-TSSOP
