ADP151ACPZ-3.3-R7
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Analog Devices |
| Package | 6-UDFN Exposed Pad, CSP |
| Datasheet | ADP151 Series |
| Description | Linear Voltage Regulator IC 1 Output 200mA 6-LFCSP-UD (2x2) |
فروشنده های ADP151ACPZ-3.3-R7
فروشگاهی یافت نشد
مشخصات ADP151ACPZ-3.3-R7
- RoHS true
- Category Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet Analog Devices ADP151ACPZ-3.3-R7
- Output Current 200mA
- Output Voltage 12V~12V
- Dropout Voltage 0.23V@(200mA)
- Output Polarity positive
- Number of Outputs 1
- Maximum Input Voltage 5.5V
- Operating Temperature -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current) 20uA
- Package LFCSP-6-UD
- Manufacturer Analog Devices
- Series -
- Packaging Cut Tape (CT)
- Part Status Active
- Output Configuration Positive
- Output Type Fixed
- Number of Regulators 1
- Voltage - Input (Max) 5.5V
- Voltage - Output (Min/Fixed) 3.3V
- Voltage - Output (Max) -
- Voltage Dropout (Max) 0.23V @ 200mA
- Current - Output 200mA
- Current - Quiescent (Iq) 20µA
- Current - Supply (Max) 350µA
- PSRR 70dB ~ 55dB (10kHz ~ 100kHz)
- Control Features Enable
- Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- Mounting Type Surface Mount
- Package / Case 6-UDFN Exposed Pad, CSP
- Supplier Device Package 6-LFCSP-UD (2x2)
- Base Part Number ADP151
- detail Linear Voltage Regulator IC 1 Output 200mA 6-LFCSP-UD (2x2)
