ATSAMD51P19A-AFT
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Microchip Tech |
| Package | 128-TQFP |
| Datasheet | SAM D5x,E5x Family Datasheet |
| Description | ARM® Cortex®-M4F Automotive, AEC-Q100, SAM D51 Microcontroller IC 32-Bit 120MHz 512KB (512K x 8) FLASH 128-TQFP (14x14) |
فروشنده های ATSAMD51P19A-AFT
فروشگاهی یافت نشد
مشخصات ATSAMD51P19A-AFT
- RoHS true
- EEPROM -
- CPU Core ARM-MSeries
- Category Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size -
- Watchdog -
- ADC (Bit) 12bit
- DAC (Bit) 12bit
- PWM (Bit) -
- Real-Time Clock -
- CPU Maximum Speed 120MHz
- GPIO Ports Number 99
- Low-Voltage Detect Yes
- CCP Capture/Compare -
- Internal Comparator -
- Internal Oscillator Yes
- Peripheral/Function PWM
- Program Memory Type FLASH
- Direct Memory Access Yes
- Program Storage Size 512KB
- Universal Serial Bus Yes
- communication protocol -
- Operating Voltage Range 1.71V~3.63V
- Infrared Data Association Yes
- Operating Temperature Range -40°C~+125°C
- Secure Digital Input and Output -
- Package TQFP-128(14x14)
- Manufacturer Microchip Tech
- Series Automotive, AEC-Q100, SAM D51
- Packaging Cut Tape (CT)
- Part Status Active
- Core Processor ARM® Cortex®-M4F
- Core Size 32-Bit
- Speed 120MHz
- Connectivity EBI/EMI, I²C, IrDA, LINbus, MMC/SD, QSPI, SPI, UART/USART, USB
- Peripherals Brown-out Detect/Reset, DMA, I²S, POR, PWM
- Number of I/O 99
- Program Memory Size 512KB (512K x 8)
- EEPROM Size -
- Voltage - Supply (Vcc/Vdd) 1.71V ~ 3.63V
- Data Converters A/D 32x12b; D/A 2x12b
- Oscillator Type Internal
- Operating Temperature -40°C ~ 125°C (TA)
- Mounting Type Surface Mount
- Package / Case 128-TQFP
- Supplier Device Package 128-TQFP (14x14)
- detail ARM® Cortex®-M4F Automotive, AEC-Q100, SAM D51 Microcontroller IC 32-Bit 120MHz 512KB (512K x 8) FLASH 128-TQFP (14x14)
