MIC5332-SSYMT-TR
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Microchip Tech |
| Package | 8-UFDFN Exposed Pad, 8-TMLF® |
| Datasheet | MIC5332-SSYMT-TR |
| Description | Linear Voltage Regulator IC 2 Output 300mA, 300mA 8-TMLF® (2x2) |
فروشنده های MIC5332-SSYMT-TR
فروشگاهی یافت نشد
مشخصات MIC5332-SSYMT-TR
- RoHS true
- Category Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet Microchip Tech MIC5332-SSYMT-TR
- Output Type Fixed
- Output Current 300mA
- Output Voltage 3.3V
- Dropout Voltage 240mV@(300mA)
- Output Polarity Positive
- Number of Outputs 2
- Maximum Input Voltage 5.5V
- Operating Temperature -40°C~+125°C
- Quiescent Current (Ground Current) 50uA
- Power Supply Rejection Ratio (PSRR) 65dB@(1kHz),45dB@(20kHz)
- Package MLF-8
- Manufacturer Microchip Tech
- Series -
- Packaging Cut Tape (CT)
- Part Status Active
- Output Configuration Positive
- Number of Regulators 2
- Voltage - Input (Max) 5.5V
- Voltage - Output (Min/Fixed) 3.3V, 3.3V
- Voltage - Output (Max) -
- Voltage Dropout (Max) 0.24V @ 300mA, 0.24V @ 300mA
- Current - Output 300mA, 300mA
- Current - Quiescent (Iq) 50µA
- Current - Supply (Max) 75µA
- PSRR 65dB ~ 45dB (1kHz ~ 20kHz)
- Control Features Enable, Power On Reset
- Protection Features Over Current, Over Temperature
- Mounting Type Surface Mount
- Package / Case 8-UFDFN Exposed Pad, 8-TMLF®
- Supplier Device Package 8-TMLF® (2x2)
- Base Part Number MIC5332
- detail Linear Voltage Regulator IC 2 Output 300mA, 300mA 8-TMLF® (2x2)
