BFU760F,115
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | NXP Semicon |
| Package | SOT-343F |
| Datasheet | BFU760F |
| Description | RF Transistor NPN 2.8V 70mA 45GHz 220mW Surface Mount 4-DFP |
فروشنده های BFU760F,115
فروشگاهی یافت نشد
مشخصات BFU760F,115
- RoHS true
- Category Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet NXP Semicon BFU760F,115
- Transistor Type NPN
- Operating Temperature +150°C@(Tj)
- Collector Current (Ic) 25mA
- Power Dissipation (Pd) 220mW
- Transition Frequency (fT) 45GHz
- DC Current Gain (hFE@Ic,Vce) 330@10mA,2V
- Collector Cut-Off Current (Icbo) 100nA
- Collector-Emitter Breakdown Voltage (Vceo) 2.8V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib) -
- Package SOT-343F
- Manufacturer NXP Semicon
- Series -
- Packaging Cut Tape (CT)
- Part Status Active
- Voltage - Collector Emitter Breakdown (Max) 2.8V
- Frequency - Transition 45GHz
- Noise Figure (dB Typ @ f) 0.4dB ~ 0.5dB @ 1.5GHz ~ 2.4GHz
- Gain -
- Power - Max 220mW
- DC Current Gain (hFE) (Min) @ Ic, Vce 155 @ 10mA, 2V
- Current - Collector (Ic) (Max) 70mA
- Mounting Type Surface Mount
- Package / Case SOT-343F
- Supplier Device Package 4-DFP
- Base Part Number BFU76
- detail RF Transistor NPN 2.8V 70mA 45GHz 220mW Surface Mount 4-DFP
فروشنده های BFU760F,115
فروشگاهی یافت نشد
