PSMN012-25YLC,115
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | NXP USA Inc. |
| Package | SC-100, SOT-669 |
| Datasheet | PSMN012-25YLC |
| Description | N-Channel 25V 33A (Tc) 26W (Tc) Surface Mount LFPAK56, Power-SO8 |
فروشنده های PSMN012-25YLC,115
فروشگاهی یافت نشد
مشخصات PSMN012-25YLC,115
- Manufacturer NXP USA Inc.
- Series -
- Packaging Cut Tape (CT)
- Part Status Obsolete
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 25V
- Current - Continuous Drain (Id) @ 25°C 33A (Tc)
- Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
- Rds On (Max) @ Id, Vgs 12.6mOhm @ 10A, 10V
- Vgs(th) (Max) @ Id 1.95V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs 8.3nC @ 10V
- Vgs (Max) ±20V
- Input Capacitance (Ciss) (Max) @ Vds 528pF @ 12V
- FET Feature -
- Power Dissipation (Max) 26W (Tc)
- Operating Temperature -55°C ~ 175°C (TJ)
- Mounting Type Surface Mount
- Supplier Device Package LFPAK56, Power-SO8
- Package / Case SC-100, SOT-669
- Base Part Number PSMN0
- detail N-Channel 25V 33A (Tc) 26W (Tc) Surface Mount LFPAK56, Power-SO8
