مشخصات BUK7226-75A/C1,118
- Manufacturer NXP USA Inc.
- Series TrenchMOS™
- Packaging Tape & Reel (TR)
- Part Status Active
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 75V
- Current - Continuous Drain (Id) @ 25°C 45A (Tc)
- Drive Voltage (Max Rds On, Min Rds On) 10V
- Rds On (Max) @ Id, Vgs 26mOhm @ 25A, 10V
- Vgs(th) (Max) @ Id 4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs 48nC @ 10V
- Vgs (Max) ±20V
- Input Capacitance (Ciss) (Max) @ Vds 2385pF @ 25V
- FET Feature -
- Power Dissipation (Max) 158W (Tc)
- Operating Temperature -55°C ~ 175°C (TJ)
- Mounting Type Surface Mount
- Supplier Device Package DPAK
- Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
- Base Part Number BUK72
- detail N-Channel 75V 45A (Tc) 158W (Tc) Surface Mount DPAK
