CD74FCT374E

CD74FCT374E

CD74FCT374E

در 2 فروشگاه

مشخصات فنی:
ManufacturerTexas Instruments
Package20-DIP (0.300", 7.62mm)
Datasheet Copper Bond Wire Revision A 04/Dec/2013
Description Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-DIP (0.300", 7.62mm)
تغییرات قیمت
مشخصات
  • Series 74FCT
  • Type D-Type
  • Package / Case 20-DIP (0.300", 7.62mm)
  • Current - Output High, Low 15mA, 48mA
  • Number of Elements 1
  • Function Standard
  • Clock Frequency 70MHz
  • Current - Quiescent (Iq) 8µA
  • Part Status Obsolete
  • Number of Bits per Element 8
  • Mounting Type Through Hole
  • Operating Temperature 0°C ~ 70°C (TA)
  • Max Propagation Delay @ V, Max CL 6.6ns @ 5V, 50pF
  • Manufacturer Texas Instruments
  • Input Capacitance 10pF
  • Voltage - Supply 4.75V ~ 5.25V
  • Packaging Tube
  • Base Part Number 74FCT374
  • Supplier Device Package 20-PDIP
  • Output Type Tri-State, Non-Inverted
  • Trigger Type Positive Edge
  • detail Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-DIP (0.300", 7.62mm)
