PCP1403-TD-H

PCP1403-TD-H

PCP1403-TD-H

در 3 فروشگاه

مشخصات فنی:
ManufacturerON Semiconductor
PackageTO-243AA
Datasheet PCP1403
Description ---
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series -
  • Packaging Cut Tape (CT)
  • Part Status Active
  • FET Type N-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 60V
  • Current - Continuous Drain (Id) @ 25°C 4.5A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On) 4V, 10V
  • Rds On (Max) @ Id, Vgs 117mOhm @ 2A, 10V
  • Vgs(th) (Max) @ Id 2.6V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs 6.7nC @ 10V
  • Vgs (Max) ±20V
  • Input Capacitance (Ciss) (Max) @ Vds 310pF @ 20V
  • FET Feature -
  • Power Dissipation (Max) 3.5W (Tc)
  • Operating Temperature 150°C (TJ)
  • Mounting Type Surface Mount
  • Supplier Device Package SOT-89/PCP-1
  • Package / Case TO-243AA
  • Base Part Number PCP1403
