FCH041N60F

FCH041N60F

FCH041N60F

در 3 فروشگاه

مشخصات فنی:
ManufacturerON Semiconductor
PackageTO-247-3
Datasheet Tape and Box/Reel Barcode Update 07/Aug/2014
Description N-Channel 600V 76A (Tc) 595W (Tc) Through Hole TO-247-3
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series SuperFET® II
  • Packaging Tube
  • Part Status Active
  • FET Type N-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 600V
  • Current - Continuous Drain (Id) @ 25°C 76A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On) 10V
  • Rds On (Max) @ Id, Vgs 41mOhm @ 38A, 10V
  • Vgs(th) (Max) @ Id 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs 360nC @ 10V
  • Vgs (Max) ±20V
  • Input Capacitance (Ciss) (Max) @ Vds 14365pF @ 100V
  • FET Feature -
  • Power Dissipation (Max) 595W (Tc)
  • Operating Temperature -55°C ~ 150°C (TJ)
  • Mounting Type Through Hole
  • Supplier Device Package TO-247-3
  • Package / Case TO-247-3
  • Base Part Number FCH04
  • detail N-Channel 600V 76A (Tc) 595W (Tc) Through Hole TO-247-3
