FGA60N65SMD

FGA60N65SMD

FGA60N65SMD

در 2 فروشگاه

تغییرات قیمت
مشخصات
  • ON SemiconductorManufacturer
  • -Series
  • TubePackaging
  • ActivePart Status
  • Field StopIGBT Type
  • 650VVoltage - Collector Emitter Breakdown (Max)
  • 120ACurrent - Collector (Ic) (Max)
  • 180ACurrent - Collector Pulsed (Icm)
  • 2.5V @ 15V, 60AVce(on) (Max) @ Vge, Ic
  • 600WPower - Max
  • 1.54mJ (on), 450µJ (off)Switching Energy
  • StandardInput Type
  • 189nCGate Charge
  • 18ns/104nsTd (on/off) @ 25°C
  • 400V, 60A, 3Ohm, 15VTest Condition
  • 47nsReverse Recovery Time (trr)
  • -55°C ~ 175°C (TJ)Operating Temperature
  • Through HoleMounting Type
  • TO-3P-3, SC-65-3Package / Case
  • TO-3PSupplier Device Package
  • FGA60Base Part Number
