FSA1256AL8X

FSA1256AL8X

FSA1256AL8X

در 3 فروشگاه

مشخصات فنی:
ManufacturerON Semiconductor
Package8-UFQFN
Datasheet FSA1256-58(A)
Description 2 Circuit IC Switch 1:1 1.15Ohm 8-MicroPak™
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series -
  • Packaging Cut Tape (CT)
  • Part Status Active
  • Switch Circuit SPST - NO
  • Multiplexer/Demultiplexer Circuit 1:1
  • Number of Circuits 2
  • On-State Resistance (Max) 1.15Ohm
  • Channel-to-Channel Matching (ΔRon) 60mOhm
  • Voltage - Supply, Single (V+) 2.7V ~ 5.5V
  • Voltage - Supply, Dual (V±) -
  • Switch Time (Ton, Toff) (Max) 35ns, 15ns
  • -3db Bandwidth 300MHz
  • Charge Injection 20pC
  • Channel Capacitance (CS(off), CD(off)) 11.5pF
  • Current - Leakage (IS(off)) (Max) 2nA (Typ)
  • Crosstalk -100dB @ 1MHz
  • Operating Temperature -40°C ~ 85°C (TA)
  • Mounting Type Surface Mount
  • Package / Case 8-UFQFN
  • Supplier Device Package 8-MicroPak™
  • Base Part Number FSA12
  • detail 2 Circuit IC Switch 1:1 1.15Ohm 8-MicroPak™
