FDMS86183

FDMS86183

FDMS86183

در 3 فروشگاه

مشخصات فنی:
ManufacturerON Semiconductor
Package8-PowerTDFN
Datasheet FDMS86183
Description N-Channel 100V 51A (Tc) 63W (Tc) Surface Mount 8-PQFN (5x6)
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series PowerTrench®
  • Packaging Cut Tape (CT)
  • Part Status Active
  • FET Type N-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 100V
  • Current - Continuous Drain (Id) @ 25°C 51A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
  • Rds On (Max) @ Id, Vgs 12.8mOhm @ 16A, 10V
  • Vgs(th) (Max) @ Id 4V @ 90µA
  • Gate Charge (Qg) (Max) @ Vgs 14nC @ 6V
  • Vgs (Max) ±20V
  • Input Capacitance (Ciss) (Max) @ Vds 1515pF @ 50V
  • FET Feature -
  • Power Dissipation (Max) 63W (Tc)
  • Operating Temperature -55°C ~ 150°C (TJ)
  • Mounting Type Surface Mount
  • Supplier Device Package 8-PQFN (5x6)
  • Package / Case 8-PowerTDFN
  • Base Part Number FDMS86
  • detail N-Channel 100V 51A (Tc) 63W (Tc) Surface Mount 8-PQFN (5x6)
